RANCANGAN INSTALASI PENCUPLIK DAN PENDETEKSI GAS KAPSUL CYRANO

ABSTRAK
RANCANGAN INSTALASI PENCUPLIK DAN PENDETEKSI GAS KAPSUL
CYRANO. Dalam rangka melengkapi sistem keselamatan fasilitas uji bahan
bakar reaktor daya (kapsul cyrano) yang berkaitan dengan keselamatan
personil operator dan peralatan di sekitar panel operasi di ruang R 0721
gedung reaktor, telah dilakukan perancangan instalasi pencuplik dan pendeteksi
gas tekan fasilitas uji tersebut. Instalasi pencuplik dan pendeteksi gas tekan
fasilitas uji bahan bakar kapsul cyrano ini merupakan sistem bantu fasilitas kapsul
cyrano tersebut. Dengan instalasi yang direncanakan keadaan gas tekan di
atas cairan NaK dapat diketahui. Rancangan yang diajukan menggunakan pipa
kecil (small tube) dari bahanbajatahankarat(SS304), dengah panjang 7500
mm. diameter luar 3.175 mm (1/8 inchi) dan tebal1,25 mm (0,049inchi), sebagai
sarana pengangkutan gas tekan.
ABSTRACT
DESIGN OF GAS SAMPLING AND DETECTION OF CYRANO
CAPSULE. Based on the requirement of safety system of the fuel pin
irradiation rig (Cyrano capsule) and to assure operator personnel and
equipment safety on surrounding area of the cyrano capsule operation panel
in reactor building, an installation design of gas sampling and detected has
been done. The installation of gas sampling and analysis of cyrano capsule is an
auxiliary system of the cyrano capsule mentioned above. By the designed
installation. the condition of gas pressure on the NaK liquid. can be detected.
The proposed design incorporates made of seamless small tube of stainless
steel 304 material with 7500 mm length, 3.175 mm diameter and 1,25 mm
thickness. and it will be used for gas transportation.
